270kgs/h Virgin Pulp Plate Making Machine Pulp Tray Making Equipment

Brand Name : NANYA

Model Number : TF-06D

Certification : CE/TUV/SGS/ISO9001

Place of Origin : China

MOQ : 1set

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50sets/month

Delivery Time : 45-120days

Packaging Details : Standard Export Packing

Target products : Degradable pulp molding dishware

Capacity : 180-270kgs/h

Cycle time : 25-30s/drop

Type of Material : Virgin pulp;Or bagasse pulp; Or bamboo pulp; Or straw pulp

Water consumption : 600-800kg/h

Material consumption : 180-270kg per hour

Drying method : Drying in mold (Thermoforming)

Mould plate size : 1100×800mm

Maximum height of products : 50mm

Minimum angle of products : 105degree

Contact Now

Pulp Plate Making Machine/ Pulp Tableware products Making Machine/ Pulp Tray Making Machine



Machine Brief Introduction



BY series pulp molding integrated machine is the semi-automatic tableware production equipment developed by NANYA company. The forming and drying/pressing workstations are combined in one machine. The forming workstation is in middle of the machine, the drying/pressing workstations are in left and right side of the machine. The working distance for operator is close, thus the efficiency is higher.



It is used for all kinds of tableware products production, paper plate, meal box, cutlery, coffee cups, etc.



Specification



 NO.              Item                   Information                         Notes
   1   Target products   Degradable pulp molding dishware
   2   Automation

automatic

(Forming, drying/pressing,

edge cutting in one macine)


   3   Capacity   180~250kg per hour
   4   Workshop Recommend   >=1600m2

  It could be adjusted according to

the user's existing workshop
   5   Type of Material   virgin pulp

Wood pulp;

Or bagasse pulp;

Or bamboo pulp;

Or straw pulp
   6   Material consumption   180-270kg per hour
  7a

  Electricity consumption

if heat by conduction oil

   230~320kw   590kw installed

  Fuel consumption

if heat by conduction oil

   Natural gas 70~90m3/h

  conduction oil boiler required:

  thermal power 800000kcal/h
  7b

  Electricity consumption

if heat by electricity

650~950kw

(no fuel consumption)

 　1450kw installed
   8   Water consumption   600-800kg/h
   9

  Chemical for Water

Resistance

   6~8kg/h
  10

  Chemical for Oil

Resistance

   1.5~2.5kg/h
  11   Operator Required   6~7 people/shift



  Application



  Food container   Dishware, tableware, lunch box, bowl, coffee cups…
  Cutlery   Fork, Knife, Spoon

270kgs/h Virgin Pulp Plate Making Machine Pulp Tray Making Equipment



270kgs/h Virgin Pulp Plate Making Machine Pulp Tray Making Equipment









 No.

           Item

                              Characteristic

                 Remarks
  1

 Overall appearance

1. Adopt forming/drying integrated structure, compact structure and convenient to operate.

2. The whole surface is covered with SUS304 stainless steel plate, with good

rust prevention, beautiful appearance and long service life.

     270kgs/h Virgin Pulp Plate Making Machine Pulp Tray Making Equipment
  2

 More homogeneous pulp supply

1. To ensure homogeneous sucking pulp during production, and the weight deviation of each product is less than 5% ,

2. Forming mold goes down into pulp tank and suck.

Concentration in the pulp tank could be less than 0.3%.


  3

 High assembly accuracy

1. The deviation of flatness and parallelism between top and bottom mold plate is less than 0.2mm, which ensures the precision when closing.

2. Four-column is made by 80mm hard chromium guide rod guiding structure, guide length of movable template is 250mm, running more smoothly and accurately.

 270kgs/h Virgin Pulp Plate Making Machine Pulp Tray Making Equipment
